TechniSat DIGITRADIO 30 User Manual

79
DE
EN
FR
NL
7.1.4 Retrieving DAB+ stations from a memory slot
> To recall a station that you have previously stored in
a memory slot, briefly press the PRESET buon to
open the memory slot.
> Select and confirm the desired station by turning
and pushing the selection knob.
If no station is saved in the selected memory slot,
[(Empty)] appears on the display.
7.1.5 Signal intensity
> Push the INFO buon repeatedly until the bar
graph showing the signal strength is shown on the
display.
Stations with a signal intensity below the required
minimum signal intensity are not transmiing a
strong enough signal. If necessary, change the
position of the radio as described in Section 5.3.2.

TechniSat DIGITRADIO 30 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	20
Number of built-in speakers	1
Package type	Box
Package depth	80 mm
Package width	275 mm
Package height	170 mm
Package weight	840 g
Power source	AC/Battery
AC input voltage	230 V
DC input voltage	3.7 V
AC input frequency	50 Hz
Projection	No
MP3 playback	-
Product color	Gray
Volume control	Rotary
On Screen Display (OSD) languages	DEU, ENG, FRE, ITA
International Protection (IP) code	IPX5
Operating temperature (T-T)	-20 - 60 °C
Headphone connectivity	3.5mm / Bluetooth
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB charging voltage	5 V
RMS rated power	2 W
Battery life	15 h
Battery type	Built-in battery
Battery capacity	3000 mAh
Bluetooth profiles	A2DP, AVRCP

Weight and Dimensions

Depth	47 mm
Width	136 mm
Height	162 mm
Weight	478 g
