TechniSat DIGITRADIO 30 User Manual

83
DE
EN
FR
NL
8.6 Audio seings
> Push the MENU buon and select [Audio seings].
> Select [Stereo available] or [Mono only] to play
back in stereo or just in mono sound if the FM
reception is weak.
Stereo playback is only possible with headphones.
8.7 Saving FM stations to a memory slot
The station memory can save up to 9 stations in
the FM range.
> First set the desired station frequency (section
8.3,8.4)
> In order to store this station in a memory slot, hold
down the PRESET buon during playback.
> Then select the desired station memory slot (1 ... 9)
by turning the selection knob.
> Complete the process by pushing the selection
knob.
Repeat this process to save additional stations.
If a favourite memory slot is selected on which a
station is already saved, it will be overwrien.

TechniSat DIGITRADIO 30 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	20
Number of built-in speakers	1
Package type	Box
Package depth	80 mm
Package width	275 mm
Package height	170 mm
Package weight	840 g
Power source	AC/Battery
AC input voltage	230 V
DC input voltage	3.7 V
AC input frequency	50 Hz
Projection	No
MP3 playback	-
Product color	Gray
Volume control	Rotary
On Screen Display (OSD) languages	DEU, ENG, FRE, ITA
International Protection (IP) code	IPX5
Operating temperature (T-T)	-20 - 60 °C
Headphone connectivity	3.5mm / Bluetooth
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB charging voltage	5 V
RMS rated power	2 W
Battery life	15 h
Battery type	Built-in battery
Battery capacity	3000 mAh
Bluetooth profiles	A2DP, AVRCP

Weight and Dimensions

Depth	47 mm
Width	136 mm
Height	162 mm
Weight	478 g
