Titan Series WinCNC Manual
WinCNC
WinCNC Controller
WinCNC Users Guide Page 15
Start Motion - This button will begin the command or job listed in the
command line.
Restart - Allows you to pick a job le and the line to start that le on.
This is useful if you want to skip over lines in a job le, or if you have
aborted a job and want to start back at the point you aborted from.
You can also choose to run the le in single step mode.
Single Step - When selected, this allows you to execute one line of
a G-Code le each time you hit ENTER.
Abort Motion - Aborts a command or job that is running.
Pause/Continue Motion - Pauses/Continues a command or job that
is running.
Open File - Opens a browse box that is used to open a job le.
View History - Opens the command history box, which allows a user
to execute a command used previously. When an error is found in
the WINCNC.INI le, the line containing the syntax error is displayed
here in red when WinCNC starts.
Edit - Opens the default editor specied in the WINCNC.INI le.
WinCNC uses Notepad by default. The editor can be used to open
job les, listed in the command line in the editor.
Simulate - Simulates a le to check for errors and run-time.
View - Opens a le for viewing in the viewer window.
Soft Limits - Enables/Disables Softlimit features.
Manual Digitize Buttons - The seven buttons on the manual digiti-
zation toolbar are for use only with the Manual Digitize feature, and
will only be visible after showing the manual digitize toolbar under
the View->Toolbars section of the menu bar.
Start a Manual Digitized File - Starts a manual digitized le and
enables the manual digitize mode.
