L400 Create Home File
Creates a home le at the machine’s current position.
L401 Recall Positions
Moves all axes to the positions where they were at previous to the
last le ran.
L500 Store Absolute Positions - L500 [X, Y, Z...] [P H T] L#
C# N”Name”
[X, Y, Z...] - axes to set positions for, if none specied then all axes
positions are stored.
[P H T] - type of position (P)osition, (H)ome Position, (T)ool Posi-
tion. Can only use one value.
L# - 0 no vertical head lift, 1 include head lift.
C# - Clearance for vertical heads if L1.
N”Name” - Name for specied position. < 16 characters long.
L500.2 - L500.2 T# N# A# C# O# H# M#
T# species the tool number.
N# species the nominal diameter for the tool.
A# species the actual diameter for the tool.
C# species the diameter compensation for the tool.
O# species the height offset for the tool.
H# species the tool height.
M# species the maximum current allowed for the tool.
This command sets up a tool library instead of using the dialog
boxes.
L501 Store Local Positions - L501 [X, Y, Z...] [P H T] L# C#
N”Name”
[X, Y, Z...] - axes to set positions for, if none specied then all axes
positions are stored.
[P H T] - type of position (P)osition, (H)ome Position, (T)ool Posi-
tion. Can only use one value.
L# - 0 no vertical head lift, 1 include head lift. Default L1.
C# - Clearance for vertical heads if L1.
N”Name” - Name for specied position. < 16 characters long.
