Personal Selection TÜV: Service & Maintenance Manual - rev. 1.0
Page 11.4
11.3. TOOLS TO USE
The following tools are necessary to carry out all disassembly, adjustment and maintenance
operations on the machines:
• Medium-sized Philips screwdriver;
• 6.5-gauge wrench;
• 8-gauge wrench;
• 13-gauge wrench;
• 14-gauge wrench;
• 17-gauge wrench;
• 22-gauge wrench;
• 2.5-gauge hexagonal T-wrench;
• 4-gauge hexagonal T-wrench;
• 5-gauge hexagonal T-wrench;
• 6-gauge hexagonal T-wrench (to use only for the floor fastening kit);
• 8-gauge hexagonal T-wrench;
• 14-gauge hexagonal T-wrench 14 (only for Leg Press bars and Abdominal and Lower Back foot
board);
• 4-gauge hexagonal L-wrench;
• Special socket wrench provided by Technogym for Ø 17 ring-nut fitting ½ (code 0Y000061);
• Special socket wrench provided by Technogym for Ø 25 ring-nut fitting ½ (code 0Y000062);
• 45-gauge hook wrench (only for side pin machines) (code 0Y000092);
• 6-mm pointed tool;
• Torque wrench;
• Hammer.
CAUTION: Tool measurements are expressed in mm.
