Personal Selection TÜV: Service & Maintenance Manual - rev. 1.0
Page 5.4
5.3. THE MACHINE IS NOT FLAT
To level the machine, you may adjust the height of the levelling foot as illustrated below:
Photo 5.3-1
We recommend that 2 people carry out
this operation.
1. Lift the machine on one side until you can
access the underside of the foot.
2. Adjust the screw a with a 8-gauge hexagonal
T-wrench, tightening it to reduce the height
of the foot and loosening it to increase the
height.
3. Lower the machine back to the floor to check
the effects of the adjustment.
4. Repeat the procedure described in point 2
until a satisfactory solution is reached.
