6.6.4 SKIPPED EFFORT LEVELS - LEVELS DO NOT CHANGE CORRECTLY WHEN THE
LEVER IS MOVED - LEVELS CHANGE WITHOUT MOVING THE LEVER
First and foremost, always update the SW to the latest release version. Remember that, from the SW
versionSKILLMILLCONNECT:HighKit:BA01.49-wi-:CA01.16;SKILLMILLCONSOLE:High
Kit:BA01.49,afunctionhasbeenaddedatSWleveltoensureacheckofthecorrectcalibration.For
the details, see “6.7 Calibrating the brake table”.
Replace the Low Kit.(*)
Yes
Yes
Yes
Yes
No
Yes
No
No
No
No
Yes
No
Problems with levels
of
difficulty
Calibrate the
brake table.
Problem solved?OK. Problem solved?
Remove the angle sensor board from
its slot and check
it is intact [1]. Board
intact?
Refit the angle sensor board [2].
Problem solved?
OK. Problem solved.
OK. Problem solved.
Fit a new angle sensor
board [2].
Problem solved?
OK. Problem solved.
There may be a faulty pin.
Replace the pin [3].
Problem solved?
Is the equipment SN prior to
DJK04D17000251?
If the equipment SN is prior
to DJK03D18001189,
DJK04D18000708,
DJK13D18000313,
DJK14D18000136, loosen
the sensor pin and then
retighten it with the torque
specied in paragraph 7.8.2.
Figure 37
Skillmill:
Technical Service Guide - Rev. 3.5
Page69email: support@technogym.com
