6.6.8 THE EFFORT LEVEL CHANGES ON THE DISPLAY WITHOUT ANYONE CHANGING
THE LEVER POSITION
First, always upgrade the SW to the latest released version.
Replace the Low
Kit.(*)
Yes
No
Yes
No
No
Yes
The effort level changes on the display
without changing the lever posi�on.
Replace the angle sensor card
[1].Problem solved?
OK.
Problem solved.
Is the equipment SN prior to
DJK03D17000505,
DJK13D17000058,
DJK04D17000251?
OK. Problem solved.
The pin may be faulty. Replace
the pin [2]. Problem solved?
Figure 42
WARNING: CAREFULLY FOLLOW THE PROCEDURE DESCRIBED BELOW.
[1]: ASSEMBLING THE ANGLE SENSOR BOARD: carefully follow the procedure
explained in paragraph “7.14.2 assembling the angle sensor board”.
