Tecnam P2010 - Page 197

AFMS N°D01 FOR GARMIN GFC700 AUTOPILOT INSTALLATION AND
RNAV/RNP NAVIGATION ELIGIBILITY
Page 1A-17
Section 1 – General
AUTOPILOT DESCRIPTION
Ed. 1, Rev. 0
PFD
MFD
AUDIO
PANEL
ADC
AHRS
MAG.
EIS
XPDR
IAU 1 IAU 2
HSDB
RS-485
RS-485
RS-232
ARINC 429
ARINC 429
ARINC 429
RS-232
RS-485
ARINC 429 ARINC 429
OAT
MASTER
CONFIG.
MODULE
CONFIG.
MODULE
CONFIG.
MODULE
CONFIG.
MODULE
RS-232
ARINC 429
RS-232
ARINC 429
RS-232
ARINC 429
ARINC 429
REVERSIONARY SWITCH
REVERSIONARY SWITCH
RS-232
RS-232
RS-232
DME
ADF
HSDB
MD-302
STAND-BY
INSTR.
STATIC
PRESSURE
PORT
TOTAL
PRESSURE
PORT
STATIC PRESSURE
TOTAL PRESSURE
HSDB
ROLL
SERVO
PITCH
SERVO
PITCH
TRIM
SERVO
RS-485
RS-485
The multifunction display (MFD) provides the pilot with a dedicated set of keys for autopilot
control (see red frame in the below picture).
The roll servo is located under the pilot seat and is fixed to a/c structure using a
dedicated mount. Pitch and pitch trim servos are located in the tail cone and are
installed on a dedicated mount which hosts both the servos.
