AFMS N°D01 FOR GARMIN GFC700 AUTOPILOT INSTALLATION AND
RNAV/RNP NAVIGATION ELIGIBILITY
AUTOPILOT FUNCTIONS
To enable or disable ESP:
1) Turn the large FMS Knob to select the AUX Page Group.
2) Turn the small FMS Knob to select the System Setup Page.
3) If necessary, select the SETUP 2 Softkey to display the AUX-SYSTEM
SETUP 2 Page.If the AUX-SYSTEM SETUP 2 is already displayed, pro-
ceed to step 4.
4) Press the FMS Knob to activate the cursor.
5) Turn the large FMS Knob to place cursor in the STABILITY & PRO-
TECTION field.
6) Turn the small FMS Knob to select ‗ENABLE‘ or ‗DISABLE‘.
7) Press the FMS Knob to remove the cursor.
ESP engagement and operation:
ESP is automatically enabled on system power up.
ESP unavailability and/or failure is indicated to the pilot on PFD by
the advisory “ESP not available” on alert window.
ESP will turn OFF upon loss of both GPS. The ADVSY “ESP OFF”
will appear on the alert window in case of loss of both GPS.
13.1.1 PITCH MODE
Pitch attitude boundaries are set based on P2010 aircraft performances. Since
pitch ESP augments the natural aircraft longitudinal stability, no special simbolo-
gy is required.
Value that have been set-up for the P2010 are as follows:
Nose above the horizon:
Engagement low threshold: + 15°
Engagement upper threshold: + 18°
Lower disengage threshold: + 12°
Nose below the horizon:
Engagement low threshold: -15°
Engagement upper threshold: -20°
Lower disengage threshold: -13°
ESP utilizes electronic torque and speed commands to augment the aircraft‘s sta-
bility: it uses an Electronic Torque Limit (ETL) and an Electronic Speed Limit
(ESL) to limit the maximum authority of the ESP function. ESP is inactive when
the pitch attitude is within the positive and negative engagement limits defined in
the certification gain file.
