Tecnam P2010 - Abnormal Procedures

AFMS N°D01 FOR GARMIN GFC700 AUTOPILOT INSTALLATION AND
RNAV/RNP NAVIGATION ELIGIBILITY
Page 3A-34
Section 3 – Emergency procedures
AUTOPILOT EMERGENCY PROCEDURES
Ed. 1, Rev. 0
12.5 ABNORMAL PROCEDURES
This table is a quick access table that provide additional information regarding re-
sidual A/P capabilities in case loss of autopilot servos and/or pitch trim servo.
With A/P engaged, in case of loss of both A/P servos and pitch trim
servo, the disconnect tone will play continuously, until acknowledged
through A/P button on MFD or trim switch on control wheel.
LOSS OF A/P
SERVO
LOSS OF
PITCH TRIM
SERVO
A/P STATUS
NOTES
A/P FUNCTIONALITY
ESP STATUS
USP STATUS
ON
OFF
ON
OFF
X
DISENGAGED
MEPT Unavailable PTRM red on PFD NO VERT MODES on PFD PTRM C&M red cross on MFD SYS page
A/P can be engaged, but
only lateral modes will be
correctly flown (lack of
pitch trim).
FD is operative in all modes
X
X
(can‘t hold 65 kts
without pitch trim
available)
X
A/P disconnect PTCH red annunciation on PFD NO VERT MODES on PFD ESP Fail on alert window PTCH C&M red cross on MFD SYS page ROLL C&M red cross on MFD SYS page
A/P can‘t be engaged
FD is operative in all modes
X
X
(only
MINSPD
warning)
X
X
A/P disconnect & MEPT Unavailable AFCS red annunciation on PFD (1‖) ESP Fail on alert window PTCH C&M red cross on MFD SYS page ROLL C&M red cross on MFD SYS page PTRM C&M red cross on MFD SYS page
A/P can‘t be engaged
FD is operative in all modes
X
X
(only
MINSPD
warning)
X
ENGAGED
MEPT Unavailable PTRM red annunciation on PFD NO VERT MODES on PFD PTRM C&M red cross on MFD SYS page
A/P fully operative
FD is operative in all modes
X
X
(can‘t hold 65 kts
without pitch trim
available)
X
A/P disconnect PTCH red annunciation on PFD NO VERT MODES on PFD ESP Fail on window alert PTCH C&M red cross on MFD SYS page ROLL C&M red cross on MFD SYS page
A/P disconnects and can‘t
be engaged
FD is operative in all modes
X
X
(only
MINSPD
warning)
X
X
A/P continuous disconnect tone can be silenced through the AP button on MFD and by the trim switch on control wheel. A/P disconnect & MEPT Unavailable AFCS red annunciation on PFD (1‖) NO VERT MODES on PFD ESP Fail on alert window PTCH C&M red cross on MFD SYS page ROLL C&M red cross on MFD SYS page PTRM C&M red cross on MFD SYS page
A/P disconnects and can‘t
be engaged
FD is operative in all modes
X
X
(only
MINSPD
warning)
NOTE
