Section 2 – Limitations
FUEL & LUBRIFICANT
5. FUEL
2 TANKS: 120 litres each one (31.7 US gallons)
MAXIMUM CAPACITY: 240 litres (63.4 US gallons)
MAXIMUM USABLE FUEL: 231 litres (61 US gallons)
APPROVED FUEL: AVGAS Grade 91/96 or 100 LL (ASTM D910)
For additional information, refer to Lycoming Service Instruction No. 1070, latest issue.
6. LUBRICANT
Recommended Grade Oil:
Average Ambient
Temperature
All Temperatures
Above 80°F
Above 60°F
30°F to 90°F
0°F to 70°F
Below 10°F
MIL-L-6082B or
SAEJ1966 Spec.
Mineral Grades
----
SAE60
SAE50
SAE40
SAE30
SAE20
MIL-L-22851 or
SAEJ1899 Spec.
Ashless Dispersant Grades
SAE15W50 or SAE20W-50
SAE60
SAE40 or SAE50
SAE40
SAE40, SAE30, SAE20W40
SAE30 or SAE20W30
For additional info, refer to “(L)IO-360-M1A Operation and Installation Manual”,
latest issue, “Operating instruction” Section.
