TECO JSDE-15 User Manual

54
Parameter Name & Functions Default Unit
Setting
Range
Control
Mode
Chapter
4
Once the home routine is activated , motor will
search for Home
position in 1
st
speed in CCW direction and
sets the Home reference position as soon as
the nearest Z (marker pulse) is detected.
When using this function, set Pn365.1=2 .
After setting the Z Phase to be the Home, it
stops in accordance with the setting of
Pn365.3.
Pn365.0
5
Once the home routine is activated , motor will
search for Home position in 1
st
speed in CW
direction and sets the Home reference
position as soon as the nearest Z (marker
pulse) is detected.
When using this function, set Pn365.1=2 .
After setting the Z Phase to be the Home, it
stops in accordance with the setting of
Pn365.3.
0 X
0
│
5
Pi
Pe
5-4-8
Once Reference Home switch or Signal, is found it
sets the search method for the Home position.
Setting Explanation
0
Once the Home Reference switch or signal is
detected, motor reverses direction in 2
nd
speed to find the nearest Z. Phase pulse and
sets this as the Home position,
then stops in accordance with Pn365.3
setting method.
1
Once the Home Reference switch or signal is
detected, motor Continues in its direction in
2
nd
speed to find the nearest Z Phase pulse
and sets this as the Home position, then stops
in accordance with Pn365.3 setting method.
Pn365.1
2
When Pn365.0=2 or 3, it finds the rising edge
of ORG to be the Home position, then stops in
accordance with Pn365.3.
When Pn365.0=4 or 5, it finds Z Phase pulse
to be the Home, then stops in accordance
with Pn365.3.
0 X
0
│
2
Setting of Home Routine Start method
Setting Explanation
0 Homing routine is Disabled.
1
On power up and activation of Servo on the
home routine is started automatically.
This method is useful for applications that do
not require repeated home routines. No
external home reference switch is required.
Pn365.2
2
Use SHOME input contact to start a home
routine.
In position mode, SHOME can be used to
start a home routine at any moment.
0 X
0
│
2
Pi
Pe
5-4-8
