A (Advanced) Parameter Summary; A091 – A104 40
Parameter
No.
LCD Display
Description
Range/Code
Factory
Setting
Remarks
A091
Auto Run
Invalid
Operation Mode
Selection During
Auto Run
0000: Auto Run mode not effective
0001: Auto Run mode for cycle.
(continue running from the
unfinished step if restarting)
0002: Auto Run mode performed
periodically (continue running
from the unfinished step if
restarting)
0003: Auto Run mode for cycle, then
hold the speed of final step to
run. (continue running from the
unfinished step if restarting)
0004: Auto Run mode for cycle.
(starting a new cycle if
restarting)
0005: Auto Run mode be performed
periodically (starting a new cycle
if restarting)
0006: Auto Run mode for one single
cycle, then hold the speed of
final step to run. (starting a
New cycle if restarting)
0000
A092
AIN Gain
AIN Gain (%)
0 - 200
100
1
A093
AIN Offset
AIN Bias (%)
0 - 100
0
1
A094
AIN Bias
AIN Bias
Selection
0000: Positive
0001: Negative
0000
1
A095
AIN Slope
AIN Slope
0000: Positive
0001: Negative
0000
1
A096
AIN Scan Time
AIN Signal
Verification Scan
Time (AIN, AI2)
(mSec x 2)
1 - 100
50
A097
AI2 Gain
AI2 Gain
(%)*(AI2)
0 - 200
100
1& *7
A098
Pulse Inp.
Mult.
Encoder Impulse
Ratio
0.001 - 9.999
1.000
A099
Ref. Source2
Select the source
of auxiliary
frequency
command
0 - 4
0
A100
A102
Reserved
Reserved
A103
AO Mode Sel
Analog Output
Voltage Mode
(0 - 10 VDC,
Term.
FM+)
0000: Output Run Frequency
0001: Input Frequency Setting
0002: Output Voltage
0003: DC Voltage
0004: Output Current
0005: PID Feedback
0000
1
A104
AO Gain
Analog Output
Gain
(%)
0 - 200
100
1
Cont.
