N3 Drive Operations Manual
A (Advanced) Parameter Summary; A105 – A117 41
Parameter
No.
LCD Display
Description
Range/Code
Factory
Setting
Remarks
A105
Relay R1 Sel
Output Relay R1
Operation Mode
0000: Run
0001: Frequency Reached (Frequency
Command) (Set Frequency
± A108)
0002: Set Frequency (A107 ± A108)
0003: Frequency Threshold Level
(> A107) - Frequency Reached
0004: Frequency Threshold Level
(< A107) - Frequency Reached
0005: Over torque Threshold Level
0006: Fault
0007: Auto Restart
0008: Momentary AC Power Loss
0009: Emergency Stop Mode
0010: Coast-to-Stop Mode
0011: Motor Overload Protection
0012: Drive Overload Protection
0013: PID Feedback Signal Loss
0014: Power on
0015: Under torque Threshold Level
0006
A106
Relay R2 Sel
Output Relay R2
Operation Mode
0000
A107
Freq Agree
Frequency Reached
(Hz) (Refer to
A105: 0001)
0.00 - 400.00
0.00
1
A108
Freq Agree
width
Frequency Reached
Bandwidth (± Hz)
0.00 - 30.00
2.00
1
A109
A110
Reserved
Reserved
A111
Trip Prevent –
ACC
Trip Prevention
Selection During
Acceleration
0000: Enable Trip Prevention
During Acceleration
0001: Disable Trip Prevention
During Acceleration
0000
A112
Trip ACC Level
Trip Prevention
Level During
Acceleration (%)
50 – 300 (Level 100% based on Motor
HP setting A003)
200
A113
Trip Prevent -
DEC
Trip Prevention
Selection During
Deceleration
0000: Enable Trip Prevention
During Deceleration
0001: Disable Trip Prevention
During Deceleration
0000
A114
Trip DEC Level
Trip Prevention
Level During
Deceleration (%)
50 – 300 (Level 100% based on Motor
HP setting A003)
200
A115
Trip Prevent -
RUN
Trip Prevention
Selection in Run
Mode
0000: Enable Trip Prevention in
Run Mode
0001: Disable Trip Prevention in
Run Mode
0000
A116
Trip Run Level
Trip Prevention
Level In Run
Mode (%)
50 - 300 (Level 100% based on Motor
HP setting A003)
200
A117
Dec Trip Time
Trip Prevention
Deceleration Time
Selection in Run
Mode
0000: Trip Prevention Deceleration
Time Set by B008
0001: Trip Prevention Deceleration
Time Set by A118
0000
Cont
