4-31
Group4- Start/Stop command group
04-01
Stopping Method Selection
Range
【0】：Enhanced braking capacity
【1】：Coast to stop
1）04-01=0：the inverter will decelerate to 0Hz in preset deceleration time after receiving the stop command.
2）04-01=1：the inverter will stop output as receiving the stop command. The motor will inertia Coast to stop.
04-03
Momentary power loss and restart
Range
【0】：Momentary Power Loss and Restart disable
【1】：Momentary power loss and restart enable
1）If the input power supply due to sudden increase in supply demand by other equipment results in voltage drops
below the under voltage level, the inverter will stop output at once. If the power supply voltage level recovers in the
04-04 preset time, it will spin start tracing from the trip frequency, or otherwise the inverter will trip with ‘LV-C’ fault
displayed.
2) 04-03=1：When the CPU is still working normally, the frequency converter is rebooted in a speed
search mode, and the number of restarts is not limited. When the CPU stops working, it cannot be
restarted.。
3) If the power failure is too long, the frequency converter will stop running; When the power supply is
restored, the operation of the frequency converter is determined according to the setting of 00-03 and
the state of the external switch, and the implementation is restarted.
04- 08
Reset Mode Setting
Range
【0】：Enable Reset Only when Run Command is Off
【1】：Enable Reset when Run Command is On or Off
04-08=0 Once the inverter is detected a fault, please turn Run switch Off and then On again to perform reset,
otherwise restarting will not be possible.
04- 09
Direct Running After Power Up
Range
【0】：Enable Direct running after power up
【1】：Disable Direct running after power up
Danger：
1） 04-09=0 and the inverter is set external terminal controlled（00-03/00-04=1）, if the run switch is
ON as power is supplied, the inverter will auto start. It is recommend that the power is turned off and the run switch is
also off to avoid possibility of injury to operators and machines as the power is reapplied.
2） 04-09=1and the inverter is set external terminal controlled（00-03/00-04=1）, if the run switch is
ON as power is supplied, the inverter will not auto start and the display will flash with STP1.
It is necessary to turn OFF the run switch and then ON to start normally.
※Note：
1. When 04-11≠0, the momentary power loss and Restart is disabled, the inverter will do KEB
Function.
2. When input power is turned off, CPU detects the DC bus Voltage and as soon as DC bus Voltage becomes lower
than 380V (440V system), then the KEB function is activated.
3. When KEB function is enabled, the inverter decelerate to zero by 04-11, and the inverter stop
4. IF the power on signal enabled during the KEB function, the inverter accelerate to original frequency.
04-15
DC Injection Brake Start Frequency (Hz) @Stopped
Range
【0.1 ~ 10.0】Hz
04-16
DC Injection Brake Level (%)@Stopped
Range
【0~ 20】%
04-17
DC Injection Brake Time (Seconds)@stopped
Range
【0.0~25.5】Sec
