Chapter 3: Menu reference > Option 14 Program Users
32 Challenger10 Administrators Manual
Your Name is Frank Smith
Press ENTER
Press [ENTER] to display the user’s PIN code (if the system is programmed to
allow users other than the master installer to see PIN codes).
Pin Code: 4346
Press ENTER
Press [ENTER] to display the user’s card data.
Card Bits: 27.0.0.0.25.0.6
Press ENTER
Press [ENTER] to exit this user record and return to the Display User screen.
Create (or modify) user
In any given Challenger panel, the process of using a RAS to create a new user,
or to modify an existing user is very similar. You need to:
• Enter the user number that you want to add or modify (in addition to the
default master installer user 50).
• Step though the LCD screens, adding or changing details as you go.
• Press [ENTER] at the end to save the details.
A basic Challenger panel used only for intrusion detection (and not access
control) might require only the most basic information such as user number,
alarm group, and PIN code. Some Challenger systems allow you to program
many other user options, such as:
• The user’s name.
• A door group and a floor group defines where the user is allowed to go and at
what times of day.
• User flags that further configure how the user’s access permissions are
handled by the Challenger system.
Some Challenger panels enable you to enter or update a user’s card data
electronically by presenting the card to the reader (called learning the card data),
or by manually entering card data.
From the Program Users menu, press [3] [ENTER] to create or modify a user.
Assuming that there is room in the user database, the following screen displays.
Create User
User No:
Enter the new or existing user number, and then press [ENTER] to select or
change the alarm group.
