3. CONFIGURING YOUR SCSI CARD
DC-395 Series User’s Manual
1313
3.2.1 Show Adapter Information
This screen displays detailed information about the SCSI chip, ROM BIOS address, I/O port
address, IRQ, PCI interrupt line, etc. The information about the SCSI Chip, IRQ Trigger
Type and Data Xfer Type is provided by the DC-395 series adapter itself. The rest of the
information in this table is provided by the mainboard's BIOS, which should support the PCI
PnP specification. This information cannot be modified.
Adapter Information
SCSI Chip …………………... TRM-S1040
Bus Type ……………………. PCI Bus
Bus# ………………………… 00h
Device# ……………………... 08h
Function# ……………………. 00h
BIOS ROM mapped at ……... C800h
IO Address ………………….. D800h
PCI Interrupt Line ………….. INTA#
IRQ# ………………………... 11
IRQ Trigger Type …………... Level triggered
Data Xfer Type ……………... PCI Bus Master
