3. CONFIGURING YOUR SCSI CARD
DC-395 Series User’s Manual
1919
3.2.3 Set Devices Options
This sub-menu allows you to change options for each device on the SCSI bus. Device
information related to each SCSI ID is displayed in the lower portion of the screen.
DC-395U/395UW/395F: MaxSyncXferRate replaced with MaxSyncXfers. Wide Negotiation
added:
SCSI ID #0 #1 #2 #3 #4 #5 #6 #7
Allow Disconnection No Yes Yes Yes Yes Yes Yes Yes
Send START UNIT Command No No No No No No No No
Tagged Command Queuing Yes Yes Yes Yes Yes Yes Yes Yes
Wide Negotiation Yes Yes Yes Yes Yes Yes Yes Yes
Synchronous Negotiation Yes Yes Yes Yes Yes Yes Yes Yes
Max Sync Xfers 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0
Included in BIOS Scan
Yes Yes Yes Yes Yes Yes Yes Yes
SCSI ID Model Device Type Capacity
0
SEAGATE
ST31230W
Fixed disk 1010 M
1
FUJITSU
M2513A
Optical disk 604 M
2
SONY
CD-R CDU924S
CD-ROM 121 M
3
NEC
CD-ROM DRIVE:462
CD-ROM
4
IOMEGA
ZIP 100
Removable disk 95 M
5
6
WANGTEK
5525ES SCSI M74H
Tape drive
7
* For DC-395UW: Press <Tab> to see the next screen for SCSI ID 8-15, if available.
* For DC-395U: "Wide Negotiation" is always set to “No” and cannot be changed.
Allow Disconnection: Yes/No. Yes is the default option and allows a SCSI device to go off-
line, thereby freeing the SCSI bus when performing multi-tasking operations. In this way, the
DC-395 can simultaneously process multiple operations on the SCSI bus and thus improve
efficiency in a multiple device environment.
Send START UNIT Command: Yes/No (default). Some specific drives require additional
spin-up commands to start their motors during system initialization. These devices would
require that this setting be set to Yes. However, most drives will spin up their motors
automatically during power up, and would not require the START UNIT Command. Some
drives have a jumper to enable/disable this option.
