2. HARDWARE SETUP
DC-395 Series User’s Manual
88
2.2 Setting the Jumpers
DC-395U/395UW/F: JP1 (LED)
SCSI Device Activity LED Indicator (JP1)
JP1 is used to indicate activity of the SCSI devices controlled by the DC-395 series adapter,
and should be connected to the cable leading to the Hard Drive LED on the front panel of
your computer case.
2.3 Setting the SCSI IDs
Each SCSI device attached to the SCSI card, as well as the card itself, must be assigned a
unique SCSI ID number. SCSI ID 7 is preset to the SCSI card, giving it the highest priority
on the SCSI bus.
The SCSI IDs of your peripheral devices are usually set with jumpers or with a switch on the
peripheral. Refer to the peripheral manufacturer’s manual to determine the ID of each device
and how to change it.
