Reference
3-58
370B User Manual
Control Required Setting
HORIZONTAL COLLECTOR
MAX PEAK POWER WATTS Less than maximum power rating of device.
COLLECTOR SUPPLY POLARITY +
CONFIGURATION EMITTER COMMON
BASE SHORT
Figure 3-35: Diode Configuration Diagram
Figure 3-36: Diode Curve
Signal Diode and
Rectifying Diodes
