Tektronix AFG3000 Series User Manual

Getting Started
AFG3000 Series Quick Start User Manual
5
Getting Started
General Features
The following table and bulleted list describe the general features of AFG3000 Series Arbitrary/Function Generators.
■ Three functions integrated into one generator:
■ 25 MHz to 240 MHz Function Generator
■ 12.5 MHz to 120 MHz Pulse Generator
■ 14 bits Arbitrary Waveform Generator
■ Color or monochrome LCD display
■ Ground isolation
■ Synchronous operation
■ USB memory interface
■ ArbExpress
®
Software
■ Context-sensitive Help system
Model AFG3021/AFG3022 AFG3101/AFG3102 AFG3251/AFG3252
Channel 1/2 1/2 1/2
Sine 25 MHz 100 MHz 240 MHz
Pulse 12.5 MHz 50 MHz 120 MHz
Memory 2 to 65,536 2 to 16,384 >16,384 to
131,072
2 to 16,384 >16,384 to
131,072
Sampling Rate 250 MS/s 1 GS/s 250 MS/s 2 GS/s 250 MS/s
Amplitude 10 V
p-p
10 V
p-p
5 V
p-p
Display Monochrome/Color Color Color
Interface USB USB, LAN, GPIB USB, LAN, GPIB

Tektronix AFG3000 Series Specifications

General

Brand	Tektronix
Model	AFG3000 Series
Category	Portable Generator
Language	English
