Tektronix AFG3000 Series User Manual

Operating Basics
54 AFG3000 Series Quick Start User Manual
USB Memory
A USB memory connector is provided with all the Tektronix AFG3000 Series Arbitrary/Function Generators to allow you to
perform the following tasks:
■ Save or recall user-defined waveforms to/from a USB memory
■ Save or recall setups to/from files on a USB memory
■ Update your arbitrary/function generator firmware
For further information on Save/Recall, see page 57. For updating your arbitrary/function generator, see page 14.
Quick Tips
■ Use a USB memory with cross section smaller than 20 mm x 12 mm to connect to the AFG3000 series front panel USB
connector. To connect a larger USB memory, use an extension cord.
■ The AFG3000 series instruments support a USB memory with FAT12, FAT16, or FAT32 file system.
CAUTION. Do not remove USB memory while writing or reading data. It may cause data loss and the USB memory may
be damaged.
When you attach a USB memory to the instrument, a caution message appears on the screen. Do not remove the USB
memory until the message disappears.
If you remove the USB memory while this caution message is displayed, it may cause damage to the instrument.
