Tektronix DPO77002SX User Manual

Instrument Channel BW settings Bandwidth
1
Sample rate
DPO77002SX ATI, 1 Ch 70 GHz BWE >67 GHz
70 GHz typical
200 GS
2
DPO77002SX
DPO73304SX
TekConnect, 2 Ch No BWE >33 GHz All
DPO77002SX
DPO73304SX
TekConnect, 2 Ch 33 GHz BWE >33 GHz 100 GS/s
DPO77002SX
DPO73304SX
TekConnect, 2 Ch
TekConnect, 4 Ch
23 GHz BWE >23 GHz 50 GS/s
DPO75902SX ATI, 1 Ch 59 GHz BWE >59 GHz 200 GS
DPO75902SX
DPO75002SX
ATI, 1 Ch 50 GHz BWE >50 GHz 200 GS
DPO75902SX TekConnect No BWE >33 GHz All
DPO75002SX TekConnect No BWE >25 GHz All
DPO75002SX TekConnect 25 GHz BWE >25 GHz 100 GS/s
DPO75002SX TekConnect 23 GHz BWE >23 GHz 50 GS/s
DPO72304SX TekConnect No BWE >23 GHz 50 GS/s, 100 GS/s
DPO72304SX TekConnect 23 GHz BWE >23 GHz 50 GS/s, 100 GS/s
DPO71604SX TekConnect 16 GHz BWE >16 GHz 50 GS/s, 100 GS/s
DPO71304SX TekConnect 13 GHz BWE >13 GHz 50 GS/s, 100 GS/s
TekConnect channel
Typical temperature derating
Frequency TC, (dB/°C) 5 °C 45 °C
DC - 5 GHz 0.005 dB/°C 0.07 -0.09
10 GHz 0.010 dB/°C 0.13 -0.17
15 GHz 0.025 dB/°C 0.33 -0.43
20 GHz 0.045 dB/°C 0.59 -0.77
23 GHz 0.10 dB/°C 1.30 -1.70
25 GHz 0.10 dB/°C 1.30 -1.70
30 GHz 0.115 dB/°C 1.50 -1.96
33 GHz 0.160 dB/°C 2.08 -2.72
ATI channel
Typical temperature derating
Frequency TC, (dB/°C)
DC - 10 GHz 0.002 dB/°C
15 GHz 0.005 dB/°C
20 GHz 0.01 dB/°C
30 GHz 0.05 dB/°C
40 GHz 0.07 dB/°C
1
To determine the amount of performance derating above the temperature limit, use the Typical Temperature Variation table.
2
200 GS/s is the only sample rate available on the ATI channel.
