Tektronix DPO77002SX User Manual

Typical temperature derating
Frequency TC, (dB/°C)
50 GHz 0.05 dB/°C
60 GHz 0.05 dB/°C
67 GHz 0.05 dB/°C
DC gain accuracy ± 2%
DC voltage measurement
accuracy, Sample, Average, and
Hi-Res modes
Full scale setting DC measurement accuracy
62.5 mV
FS
– 6 V
FS
3
±(Gain accuracy x | vertical value - net offset |) +
offset accuracy + 0.4% x FS
Delta voltage reading
62.5 mV
FS
– 6 V
FS
±(Gain accuracy x | Delta voltage measured | +
0.008 x FS
Offset accuracy
Full scale voltage range Offset accuracy
62.5 mV
FS
to 1.2 V
FS
(TekConnect channels) ±(0.4% | net offset | + 0.2% | net offset – Vterm
setting | + 2.5 mV + 1% FS)
>1.2 V
FS
to 6 V
FS
(TekConnect channels) ±(0.6% | net offset | + 13.4 mV + 1% FS)
100 mV
FS
to 300 mV
FS
(ATI channel) ±(0.35% | net offset | + 2 mV + 1% FS)
Maximum input voltage
TekConnect channels: ≤1.2 V
FS
settings:
±1.5 V relative to the termination bias (30 mA maximum)
±5 V absolute maximum input
>1.2 V
FS
settings:
±8 V. Limited by maximum Vterm current and the attenuator power rating at maximum
temperature.
ATI channel: ±0.75 V
pk
Aux channel: ±5.0 V
pk
3
For ATI channels, the full scale settings range is 100 mV
FS
to 300 mV
FS
.
Vertical system analog channels (cont.) Specifications
DPO70000SX Series User 189
