Command Groups
Table 2-41: Trigger Commands (cont.)
Command
Description
TRIGger:A:BUS:B<x>:ETHERnet:MAC{:LENgth|:
TYPe}:VALue
When the Ethernet trigger condition is set to MACLENgth, and the qualifier is
set to
LESSthan, MOREthan, EQual, UNEQual, LESSEQual or
MOREEQual, this command speci fi es the 16–bit value to trigger on.
TRIGger:A:BUS:B<x>:ETHERnet:QTAG:VALue When the Ethernet trigger condition is set to QTAG, this command specifies
the 32–bit Q-Tag value to trigger on.
TRIGger:A:BUS:B <x >:ETH E R net:QU ALifier This command specifies the qualifi er to be used when the Ethernet trigger
condition is set to
MACLENgth or DATa.
TRIGger:A:BUS:B<x>:ETHERnet:TCPHeader:
ACKnum:VALue
When the Ethernet trigger condition is set to
TCPHeader, this command
specifies the 32–bit acknowledgement number that is to be used in the trigger
(along with the destination and source port addresses and the sequence
number).
TRIGger:A:BUS:B<x>:ETHERnet:TCPHeader:
DESTinationport:VALue
When the Ethernet trigger condition is set
TCPHeader, this command
specifies the 16–bit destination port address value that is to be used in the
trigger (along with the acknowledgement value, source port address and the
sequence number).
TRIGger:A:BUS:B<x>:ETHERnet:TCPHeader:
SEQnum:VALue
When the Ethernet trigger condition is set to
TCPHeader, this command
specifies the 32–bit sequence number that is to be used in the trigger (along
with the destination and source port addresses and the acknowledgement
value).
TRIGger:A:BUS:B<x>:ETHERnet:TCPHeader:
SOUrceport:VALue
When the Ethernet trigger condition is set to
TCPHeader, this command
specifies the 16–bit source port address that is to be used in the trigger
(along with the destination port address, the sequence number and the
acknowledgement number).
TRIGger:A:BUS:B<x>:FLEXray:CONDition This command specifies the condition to use when triggering on a FlexRay
bus signal (start of frame, frame type, ID, cycle count, header, data, ID and
data, EOF, error).
TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:
HIVALue
This command specifies the high v alue when triggering on a FlexRay bus
cycle count field.
TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:
QUALifier
This command specifies the qualifier (<, >, =, <=, >=, not =, in range, out of
range) to use when triggering on the FlexRay bus cycle count field.
TRIGger:A:BUS:B<x>:FLEXray:CYCLEcount:
VALue
This command specifies the low value when triggering on the FlexRay bus
cycle count field.
TRIGger:A:BUS:B<x>:FLEXray:DATa:HIVALue This command specifies the h igh value when triggering on the FlexRay bus
data field.
TRIGger:A:BUS:B<x>:FLEXray:DATa:OFFSet This command specifies the o ffset o f the data string, in bytes, when triggering
on the FlexRay bus data field.
TRIGger:A:BUS:B<x>:FLEXray:DATa:QUALifier This command specifies the qualifier (<, >, =, <=, >=, not =, in range, out of
range) to use when triggering on the FlexRay bus data field.
TRIGger:A:BUS:B<x>:FLEXray:DATa:SIZe This command specifies the length of the data string, in bytes, when triggering
on the FlexRay bus data field.
TRIGger:A:BUS:B<x>:FLEXray:DATa:VALue This command specifies the low value when triggering on the FlexRay bus
data field.
