Tektronix MDO4000B Series User Manual

Command Groups
Table 2-41: Trigger Commands (cont.)
Command
Description
TRIGger:A:BUS :B<x>:CAN:FD:BRSBIT This command sets the value (don’t care, 1, or 0) to be used to trigger on
CANFDBRSbits
TRIGger:A:BUS :B<x>:CAN:FD:ESIBIT This command sets the value (don’t care, 1, or 0) to be used to trigger on
CAN FD ESI bits
TRIGger:A:BUS :B<x>:CAN:FRAMEtype This command sets the frame type (data, remote, error or overload) to be used
when triggering on a CAN bus signal.
TRIGger:A:BUS :B<x>:CA N{:IDentifier|:ADDRess}:
MODe
This command sets the addressing m ode (standard o r extended format) to be
used when triggering on a CAN bus signal.
TRIGger:A:BUS :B<x>:CA N{:IDentifier|:ADDRess}:
VALue
This command sets the binary address value to be used when triggering on a
CAN bus signal.
TRIGger:A:BUS:B<x>:ETH E R net:C ON Dition This command specifies a field o r condition within an Ethernet frame to trigger
on.
TRIGger:A:BUS:B<x>:ETHERnet:DATa:HIVALue When the Ethernet trigger condition is set to DATa, and the qualifier is set to
either
INrange orOUTrange, this command specifies the upper data value
of the range.
TRIGger:A:BUS:B<x>:ETHERnet:DATa:OFFSet When the Ethernet trigger condition is set to DATa, this command specifies
where in the data field to look for the data trigger value.
TRIGger:A:BUS :B<x>:ETH ER net:DATa:S IZe When the Ethernet trigger condition is set to DATa, this command specifies
the number of contiguous TCP/IPv4/MAC client data bytes to trigger on.
TRIGger:A:BUS:B<x>:ETHERnet:DATa:VALue When the Ethernet trigger condition is set to DATa, and the qualifier is set
to
LESSthan, MOREthan, EQual, UNEQual , LESSEQual or
MOREEQual, this command specifies the value to trigger on.
TRIGger:A:BUS:B<x>:ETH E R net:FR AM E T YPe This command specifies the Ethernet frame type: either Basic or QTag (IEEE
802.1Q, or V LAN tagging).
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:
DESTinationaddr:VALue
When the Ethernet trigger condition is set to
IPHeader, this command
specifies the value of the 32–bit destination address that is to be used in the
trigger (along with the source address and protocol value).
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:
PROTOcol:VALue
When the Ethernet trigger condition is set to
IPHeader, this command
specifies the value of the 8–bit protocol field that is to be used in the trigger
(along with the s ource and destination addresses).
TRIGger:A:BUS:B<x>:ETHERnet:IPHeader:
SOUrceaddr:VALue
When the Ethernet trigger condition is set to
IPHeader, this command
specifies the value of the 32–bit source address that is to be used in the trigger
(along with the destination address and protocol value).
TRIGger:A:BUS:B<x>:ETHERnet:MAC:ADDR e ss:
DESTination:VALue
When the Ethernet trigger condition is set to
MACADDress , this command
specifies the 48–bit MAC destination address that is to be used in the trigger
(along with the source address value).
TRIGger:A:BUS:B<x>:ETHERnet:MAC:ADDR e ss:
SOUrce:VALue
When the Ethernet trigger condition is set to
MACADDress , this command
specifies the 48–bit MAC source address value that is to be used in the trigger
(along with the destination address value).
TRIGger:A:BUS:B<x>:ETHERnet:MAC{:LENgth|:
TYPe}:HIVALue
When the Ethernet trigger condition is set to MACLENgth, and the qualifier
is set to
INrange or OUTrange, this command specifies the upper data
value of the range.
2-82 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
