Command Groups
Table 2-41: Trigger Commands (cont.)
Command
Description
TRIGger:A:BUS:B<x>:ARINC429A:DATA:
QUALifier
This command sets the qualifier (<, >, =, <=, >=, not =, in range, out of range)
to use when triggering on a ARINC429 bus data field.
TRIGger:A:BUS:B<x>:ARINC429A:DATA:VALue This command specifies the low value to use when triggering on a ARINC429
bus data field.
TRIGger:A:BUS:B<x>:ARINC429A:ERRTYPE This command speci fies the error type to use when triggering on a ARINC429
bus signal.
TRIGger:A:BUS:B<x>:ARINC429A:LABel:
HIVALue
This command specifies the high value to use when triggering on a ARINC429
bus label field.
TRIGger:A:BUS:B<x>:ARINC429A:LABel:
QUALifier
This command sets the qualifier (<, >, =, <=, >=, not =, in range, out of range)
to use when triggering on a ARINC429 bus label field.
TRIGger:A:BUS:B<x>:ARINC429A:LABel:VALue This command specifies the low value to use when triggering on a ARINC429
bus label field.
TRIGger:A:BUS:B<x>:ARINC429A:SDI This command specifies the SDI portion of the packet data to be used when
triggering on ARINC429 bus data.
TRIGger:A:BUS:B<x>:ARINC429A:SSM This command specifies the SSM portion of the packet data to be used when
triggering on a ARINC429 bus data.
TRIGger:A:BUS:B <x>:AUDio:CONDition This command sets the condition (start of frame or matching data) to be used
when triggering on an audio bus signal.
TRIGger:A:BUS:B<x>:AUDio:DATa:HIVALue
This command sets the upper word value to be used when triggering on an
audio bus signal.
TRIGger:A:BUS:B <x >:AUD io:D ATa:OFFSet This command sets the data offset value to be used when triggering on an
audio bus signal.
TRIGger:A:BUS:B <x >:AUD io:D ATa:QUALifier This command sets the qualifier (<, >, =, <=, >=, not =, in range, out of range)
to be used when triggering on an audio bus signal.
TRIGger:A:BUS:B<x>:AUDio:DATa:VALue
This command sets the l ower word value to be used when triggering on an
audio bus signal.
TRIGger:A:BUS:B <x>:AUDio:DATa:WORD This command sets the alignment of the data (left, right or either) to be used to
trigger on an audio bus signal.
TRIGger:A:BUS:B <x>:CAN:CONDition This command sets the condition (start of frame, frame type, identifier,
matching data, end of frame, missing ACK field, bit-stuffing error, form error,
any error, CAN FD BRS bit, or CAN FD ESI bit) to be used when triggering
on a CAN bus signal.
TRIGger:A:BUS:B <x >:CAN:DATa:DIRection This command sets the data direction (read, write or “nocare”) to be used to
search on a CAN bus signal.
TRIGger:A:BUS:B <x >:CAN:DATa:OFFSet This command specifies the data offset for CAN data triggering
TRIGger:A:BUS:B <x >:CAN :DATa:QUALifier This command sets the qualifier (<, >, =, not =, <=) to be used when triggering
on a CAN bus signal.
TRIGger:A:BUS:B <x>:CAN:DATa:SIZe This command sets the length of the data string, in bytes, to be used when
triggering on a C AN bus signal.
TRIGger:A:BUS:B<x>:CAN:DATa:VALue
This command sets the binary data value to be used when triggering o n a
CAN bus signal.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-81
