Appendix H: List of Beta Commands and Features

AFG:MODULatio

n:AM:DEPth 100

AFG:OUTPut:STATE 1

The AFG can be conﬁgured to burst play the current signal 1 time, with a 1 ms

interval between bursts using the following sequence of commands:

AFG:RUNMode BURst

AFG:TRIGger:COUnt 1

AFG:TRIGger:INTerval 1.0e-3

AFG:OUTPut:STATE 1

AFG:TRIGger (No Query Form)

Description:

ForcesasoftwaretriggeroftheAFG.

Conditions:

Beta Command, see conditions of use.

Group:

AFG

Syntax:

AFG:TRIGger {FORCE}

Arguments:

FORCe (optional) - Force software trigger.

Examples:

AFG:TRIGger FORCe will force the software AFG trigger.

AFG:TRIGger:COUnt

Description:

Sets the trigger count for the AFG.

Conditions:

Beta Command, see conditions of use. Default setting is 0.

Group:

AFG

Syntax:

AFG:TRIGger:COUnt <NR1>

AFG:TRIGger:COUnt?

MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual H-7
