Commands Listed in Alphabetical Order
Conditions
This command re
quires a DPO4EMBD application module for 4000 series
models, and an MDO3EMBD application module for MDO3000 series models.
Group
Bus
Syntax
BUS:B<x>:SPI{:SELect|:SS}:SOUrce {CH1|CH2|CH3|C H4|
D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D11| D12|D13|D14|D15}
BUS:B<x>:SPI{:SELect|:SS}:SOUrce?
Arguments
CH1–CH4 specifies an analog channel as the source waveform.
D0-D15 specifies a digital channel as the source waveform.
(MSO/MDO4000/B models only as well as MDO3000 and MDO400C models
with option MDO3MSO or MDO4MSO installed.)
BUS:B<x>:STATE
This command specifies the on/off state of the bus.
Group
Bus
Syntax
BUS:B<x>:STATE {<NR1>|OFF|ON}
BUS:B<x>:STATE?
Related Commands
SELect:{BUS<x>|B<x>}
Arguments
ON or <NR1> ≠0turnsonthebus.
OFF or <NR1> =0turnsoffthebus.
BUS:B<x>:TYPe
This command specifies (or queries) the bus type. The supported bus types are
dependent on the oscilloscope model and the installed application models. With
the exception of the parallel bus, all bus types require installation of an application
module. (Seepage2-15,Bus Command Group.)
NOTE. The PARallel bus is available on MSO/MDO4000/B models only as well
as MDO3000 and MDO400C models with option MDO3MSO or MDO4MSO
installed.
2-200 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
