Commands Listed in Alphabetical Order
MARKER:M<x>:
AMPLitude:DELTa? (Query Only)
This query returns the delta amplitude (vertical) value of either of the two
manual markers that are available for frequency domain traces, in relationtothe
Reference Ma
rker. M<x> can be either M1, which specifies manual marker a,or
M2, which specifies manual marker b.
NOTE. Querying the delta of M1 will always return 0, because M1 is always the
Reference Marker when manual markers are turned on.
Conditions
MDO3000, MDO4000/B, or MDO4000C models with option SA3 or SA6 only.
Group
RF
Syntax
MARKER:M<x>:AMPLitude:DELTa?
Related Commands
MARKER:MANual, MARKER:M<x>:AMPLitude:ABSolute?,
MARKER:M<x>:FREQuency:DELTa?, MARKER:M<x>:FREQuency:ABSolute
Examples
MARKER:M2:AMPLitude:DELTa? might return –5.0E+00, indicating that marker
b is –5 dBc below marker a, which is also the Reference Marker.
MARKER:M<x>:FREQuency:ABSolute
This command specifies the actual frequency (horizontal) value of either ofthe
two manual markers that are available for frequency domain traces. M<x> can
be either M1, which specifies manual marker a, or M2, which specifies manual
marker b.
NOTE. Markers cannot be placed outside the frequency range defined by
RF:STARt and RF:STOP.
Conditions
MDO3000, MDO4000/B, or MDO4000C models with option SA3 or SA6 only.
Group
RF
Syntax
MARKER:M<x>:FREQuency:ABSolute <NR3>
MARKER:M<x>:FREQuency:ABSolute?
2-360 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
