Bus search selection list
From the Search Configure window, select a bus source to set up from the list of Source selections <B1-B16>.
To use
■
Select the Search Slot from the drop-down list.
■
Click and turn (drag) the scroll wheel or click the up/down arrows until the desired Bus number or name is visible.
■
Click the Bus number <B1–B16> or name to be set up.
■
Click OK.
Behavior
Click the OK to return to the Search Configure .
What do you want to do next?
Learn more about bus setups.
Learn about bus configuration.
Learn about digital setups.
Bus setups
110 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
