Set up an edge trigger
From the Trig menu, select Edge Setup.
Overview. Use the controls in this window to set up Edge trigger parameters for general-purpose testing.
To use. For information on the controls, click the buttons.
■
Trigger Type
■
Mark All Trigger Events
■
Settings
■
Source
■
Set to 50%
■
Level
■
Coupling
■
Slope
■
Force Trigger
■
Envelope
The following Trigger Edge screen appears on MSO70000C/DX Series instruments:
The following Trigger Edge screen appears on DPO70000SX Series instruments:
Trigger setups
414 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series

Tektronix MSO71604C Specifications

General

Bandwidth	16 GHz
Channels	4
Sample Rate	50 GS/s
Analog Channels	4
Digital Channels	16
Rise Time	22 ps
Input Coupling	AC, DC, GND
Operating Temperature	0 °C to +50 °C
Vertical Resolution	8 bits
Display	12.1-inch LCD
Input Impedance	1 MΩ
Maximum Input Voltage	5 Vrms
Trigger Types	Edge, Pulse, Runt, Window, Logic, Setup/Hold, Rise/Fall Time, Video, Serial
Interface	USB, LAN
