Tektronix MSO71604C Printable Help

Introduction
This Tektronix oscilloscope provides the performance, simplicity, and connectivity needed for the ever-changing electronics,
computer, and communications industries. The easy-to-use interface includes a large display and a touch-screen interface on a
Microsoft Windows platform.
Choose the methods of controlling oscilloscope operations that are most convenient for you:
■
Customary front-panel controls
■
Menus and toolbar buttons
■
Touch screen
What do you want to do next?
Product description on page 1
Online help on page 32
Working with your oscilloscope on page 865
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series xxvii

Tektronix MSO71604C Specifications

General

Bandwidth	16 GHz
Channels	4
Sample Rate	50 GS/s
Analog Channels	4
Digital Channels	16
Rise Time	22 ps
Input Coupling	AC, DC, GND
Operating Temperature	0 °C to +50 °C
Vertical Resolution	8 bits
Display	12.1-inch LCD
Input Impedance	1 MΩ
Maximum Input Voltage	5 Vrms
Trigger Types	Edge, Pulse, Runt, Window, Logic, Setup/Hold, Rise/Fall Time, Video, Serial
Interface	USB, LAN
