Tektronix MSO71604C

■
Opt. SR-ENET - Ethernet Serial Analysis (10BASE-T and 100BASE-TX)
■
Opt. SR-PCIE - PCI Express Compliance Module for RT-Eye Serial Data Compliance and Analysis
■
Opt. SR-USB - USB Serial Triggering and Analysis (LS, FS, HS)
■
Opt. SR-810B - 8b/10b Serial Triggering and Analysis
■
Opt. ST1G – 64-bit NRZ Serial Trigger and 8b/10b Serial Protocol Decode (includes Opt. SR-810B) (only available on
DPO7254C/DPO7354C instruments)
■
Opt. SV23 - WLAN 802.11a/b/g measurement application (Requires Opt. SVE) (For models of bandwidth ≥2.5 GHz only)
■
Opt. SV24 - WLAN 802.11n measurement application (Requires Opt. SVE and SV23) (For models of bandwidth ≥2.5 GHz
only)
■
Opt. SVA - SignalVu AM/FM/Direct Audio Measurements (requires SVE)
■
Opt. SVE - SignalVu
™
Essentials for Vector Signal Analysis
■
Opt. SVM - General Purpose Modulation Analysis (requires SVE)
■
Opt. SVO - Flexible OFDM Analysis (requires SVE)
■
Opt. SVP - SignalVu Pulse — Advance Signal Analysis Software (requires SVE)
■
Opt. SVT - Settling Time Measurements such as Frequency and Phase (requires SVE)
■
Opt. USB - Universal Serial Bus USB2.0 Compliance Test
■
Opt. USBHSIC - USB2.0 and HSIC Bundle, includes options Opt. DJA, HSIC, SR-USB, and USB
■
Opt. USBPWR - USB Power Adapter/ EPS Compliance Automated Test Solution
MSO/DPO70000C/DX:
■
Calibration:
■
Opt. C3 - Calibration service 3 years
■
Opt. C5 - Calibration service 5 years
■
Opt. D1 - Calibration data report
■
Opt. D3 - Calibration data report 3 years (with Opt C3)
■
Opt. D5 - Calibration data report 5 years (with Opt C5)
■
Hardware:
■
Opt. 1R - Rackmount kit
■
Record Length:
MSO70000C/DX, and DPO70000C/DX Series:
■
Opt. 2XL - 31 MSamples/ch (standard on DPO instruments)
■
Opt. 5XL - 62 MSamples/ch (standard on MSO instruments)
■
Opt. 10XL - 125 MSamples/ch
■
Opt. 20XL - 250 MSamples/ch
■
Opt. 50XL - 500 MSamples/ch
■
Service:
About Tektronix oscilloscopes
12 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
