Tektronix MSO71604C Printable Help

To use. For information on the controls, click the buttons.
■
Trigger Type
■
Mark All Trigger Events
■
Settings
■
Source
■
Set to 50%
■
Level
■
Timer
■
Trigger When
■
Qualification
■
Pattern
■
Edit Button
■
HF Filtering
■
Envelope
NOTE. The Trigger Timeout screen on DPO and MSO instruments is the same except for the source selection (MSO instruments
include digital channels) and Trigger if Timeout Qualification options. In some instruments, the source selection is a drop-down
list and the Trigger if Timeout Qualification option has Occurs and Logic. In other instruments the source selection includes a
combo list and a Select button. The Trigger if Timeout Qualification option has Occurs, Logic, and Occurs And.
The following Trigger Timeout screen appears on MSO70000C/DX and DPO7000C Series instruments:
The following Trigger Timeout screen appears on DPO70000SX Series instruments:
Trigger setups
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 431

Tektronix MSO71604C Specifications

General

Bandwidth	16 GHz
Channels	4
Sample Rate	50 GS/s
Analog Channels	4
Digital Channels	16
Rise Time	22 ps
Input Coupling	AC, DC, GND
Operating Temperature	0 °C to +50 °C
Vertical Resolution	8 bits
Display	12.1-inch LCD
Input Impedance	1 MΩ
Maximum Input Voltage	5 Vrms
Trigger Types	Edge, Pulse, Runt, Window, Logic, Setup/Hold, Rise/Fall Time, Video, Serial
Interface	USB, LAN
