Command Descriptions
TDS Family Oscilloscope Programmer Manual
2–89
specifies the ASCII representation of signed integer () data. If
this is the value at power-on, the WFMPre values for BN_Fmt, BYT_Or, and
ENCdg are set as RP, MSB, and ASC respectively.
specifies signed integer data-point representation with the most
significant byte transferred first. This format results in the fastest data transfer
rate when DATa:WIDth is set to 2.
The range is –128 to 127 when DATa:WIDth is 1. Zero is center screen. The
range is –32768 to 32767 when DATa:WIDth is 2. The upper limit is one
division above the top of the screen and the lower limit is one division below the
bottom of the screen.
specifies positive integer data-point representation with the most
significant byte transferred first.
The range is 0 to 255 when DATa:WIDth is 1. 127 is center screen. The range is
0 to 65,535 when DATa:WIDth is 2. The upper limit is one division above the
top of the screen and the lower limit is one division below the bottom of the
screen.
is the same as except that the byte order is swapped,
meaning that the least significant byte is transferred first. This format is useful
when transferring data to IBM compatible PCs.
is the same as except that the byte order is swapped,
meaning that the least significant byte is transferred first. This format is useful
when transferring data to IBM compatible PCs.
Arguments
