Command Descriptions
2–90
TDS Family Oscilloscope Programmer Manual
Table 2–27: DATa and WFMPre Parameter Settings
WFMPre Settings
D
:E
Cd
S
tt
n
:ENCdg :BN_Fmt :BYT_Or
ASCIi ASC
N/A N/A
RIBinary BIN RI MSB
RPBinary BIN RP MSB
SRIbinary BIN RI LSB
SRIbinary BIN RP LSB
DATA:ENCDG RPBINARY
sets the data encoding format to be positive integer where the most significant
byte is transferred first.
DATA:ENCDG?
might return SRPBINARY for the format of the waveform data.
DATa:SOUrce
Sets or queries the location of the waveform data that is transferred from the
instrument by the CURVe? query. The source data is always transferred in a
predefined order regardless of the order they are specified using this command.
The predefined order is CH1 through CH4, MATH1 through MATH3, then
REF1 through REF4.
Waveform
DATa:SOUrce <wfm>[<Comma><wfm>]...
DATa:SOUrce?
SOUrce
DATa :
<Space>
?
<wfm> <Comma> <wfm>
<wfm> is the location of the waveform data that will be transferred from the
digitizing oscilloscope to the controller.
Examples
Group
Syntax
Arguments
