Status and Events
3–18
TDS Family Oscilloscope Programmer Manual
Table 3–7: System Event Messages (Cont.)
Code Message
461 Bottom menu button #2 pushed (URQ bit 6 set)
462 Bottom menu button #3 pushed (URQ bit 6 set)
463 Bottom menu button #4 pushed (URQ bit 6 set)
464 Bottom menu button #5 pushed (URQ bit 6 set)
465 Bottom menu button #6 pushed (URQ bit 6 set)
466 Bottom menu button #7 pushed (URQ bit 6 set)
Table 3–8 lists warning messages that do not interrupt the flow of command
execution. These notify you that you may get unexpected results.
Table 3–8: Execution Warning Messages – EXE Bit 4
Code Message
500 Execution warning
510 String data too long, truncated
525 Parameter underrange
526 Parameter overrange
527 Parameter rounded
528 Parameter out of range
530 Data stop > stop, Values swapped internally
531 Data stop > record length, Curve truncated
532 Curve data too long, Curve truncated
540 Measurement warning
541 Measurement warning, Low signal amplitude
542 Measurement warning, Unstable histogram
543 Measurement warning, Low resolution
544 Measurement warning, Uncertain edge
545 Measurement warning, Invalid in minmax
546 Measurement warning, Need 3 edges
547 Measurement warning, Clipping positive/negative
548 Measurement warning, Clipping positive
549 Measurement warning, Clipping negative
