Command Descriptions
TDS Family Oscilloscope Programmer Manual
2–197
and = 0 to 640, and are pixel positions along the horizontal axis.
defines the left and defines the right side of the window.
and = 0 to 480, and are pixel positions along the vertical axis.
defines the top and defines the bottom of the window. The reserved height
of all characters is 15 pixels so the window must be at least that high to fully
display characters. For a complete list of character widths in pixels, see Table
A–1 on page A–1. Shorter windows clip characters.
Figure 3-1 shows the coordinate system relative to the screen.
0
34
84
480
134
184
234
284
334
384
434
0
24
74
124
174
224
274
324
374
424
474
524
640
Figure 2–4: Message Window Coordinates
Syntax
Arguments
