Command Syntax
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
2-9
RS-232 End of Message Terminators. RS-232 EOM terminators can be a
CR (carriage return), LF (line feed), CRLF (carriage return followed
by a line feed), or LFCR (line feed followed by a carriage return).
When receiving, the oscilloscope accepts all four combinations as
valid input message terminators regardless of the currently selected
terminator. When a combination of multiple characters is selected
(CRLF or LFCR), the oscilloscope interprets the first character as the
terminator and the second character as a null command.
Constructed Mnemonics
Some header mnemonics specify one of a range of m nemonics. For
example, a channel mnemonic could be CH2. You can use these
mnemonics in the command just as you do any other mnemonic. For
example, there is a CH1:VOLts command and there is also a
CH2:VOLts command. In the command descriptions, this list of
choices is abbreviated CH<x>.
Channel Mnemonics
Commands specify the channel to use as a mnemonic in the header.
Symbol Meaning
CH<x> 2-channel models: A channel specifier; <x> is 1 or 2.
4-channel models: A channel specifier; <x> is 1, 2,
3, or 4.
Reference Waveform Mnemonics
Commands can specify the reference waveform to use as a
mnemonic in the header.
Symbol Meaning
REF<x> 2-channel models: A reference waveform specifier;
<x> is A or B.
4-channel models: A reference waveform specifier;
<x>isA,B,C,orD.
