Command Syntax
2-10
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
Waveform M nemonics
In some c ommands you can specify a waveform without regard to its
type: channel waveform , math waveform, or reference waveform.
The “y” is the same as “x” in Reference Waveform Mnemonics.
Symbol Meaning
<wfm> Can be CH<x>, MATH, or REF<y>
Cursor Position Mnemonic
When the oscilloscope displays cursors, commands may specify
which cursor of the pair to use.
Symbol Meaning
POSITION<x>
A cursor selector; <x> is 1 or 2.
Measurement Specifier Mnemonics
Commands can specify which measurement to set or query as a
mnemonic in the header. The oscilloscope can display up to four
(TDS200) or five (TDS1000, T DS2000, TDS1000B, T DS2000B, and
TPS2000) automated measurements.
Symbol Meaning
MEAS<x> A measurement specifier; <x> is 1--4 (TDS200)
or 1--5 (TDS1000, TD S2000, TDS1000B,
TDS2000B, and TPS2000).
