Command Groups
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
2-29
Table 2- 20: Power Measurement commands (TPS2000 with TPS2PWR1
only)
Header Description
HARmonics? Return all harmonic parameters
HARmonics:ENABle Set or query the harmonics menu on and off
HARmonics:FREquency? Return the frequency of the selected harmonic
HARmonics:HRMS? Return the frequency of the selected harmonic
HARmonics:PERCent? Return the amplitude of the selected harmonic as a
percent of the fundamental
HARmonics:PHAse? Return the phase of the selected harmonic, in
degrees, relative to the fundamental
HARmonics:RMS? Return the amplitude of the harmonics source in
RMS units. This may be V
rms
or I
rms
depending on
the type of source waveform
HARmonics:SAVe Set the file name and path to save harmonic data
HARmonics:SELect Set or query the selected harmonic
HARmonics:SETUp Set or query the operating mode for harmonics
measurements commands
HARmonics:SHOW Set or query the specified harmonics
HARmonics:SOUrce Set or query the source in the harmonics menu
HARmonics:THDF? Query the total harmonic distortion of the waveform
as percent of fundamental
HARmonics:THDR? Query the total harmonic distortion of the waveform
as % of input V
rms
POWerANALYSIS:SOUrces Sets or query the power analysis sources
SWLoss? Return switching loss measurement settings
SWLoss:ACQuire Set or query the type of acquisition to use for
Switching Loss commands
SWLoss:AVErage:CONDUCTION? Return the power loss of the device under test when
the device is conducting
