Command Groups
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
2-37
Table 2- 25: Vertical commands (Cont.)
Header Description
CH<x>:INVert
(
All oscilloscope, firmware version,
and module combinations except
TDS210 and TDS220 with firmware
below V 2.00 and a TDS2CMA
communications module.
)
Set or query the channel invert
CH<x>:POSition Set or query the channel position
CH<x>:PRObe Set or query the channel probe parame-
ters
CH<x>:SCAle Set or query the channel volts/div
CH<x>:VOLts Same as CH<x>:SCAle
CH<x>:YUNit
(TDS1000B, TDS2000B, and
TPS2000 only)
Set or query the units of the specified
channel
SELect? Controls the display of waveforms
SELect:<wfm> Set or query the waveform display state
Waveform Commands
Waveform commands let you transfer waveform data points to and
from the oscilloscope. Waveform data points are a collection of
values that define a waveform. One data value usually represents one
data point in the waveform rec ord. W hen working with peak-detect
waveforms, each data value is either the min or max of a min/max
pair. Before you can transfer waveform data, you must specify the
data format and waveform locations.
Table 2--26 lists and describes Waveform commands. Refer to the
text following this table for more information about waveform
commands.
