Command Descriptions
2- 190
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
MASK:TEST:REPEAT ON
causes the oscilloscope to continuously repeat the pass/fail test.
MASK:TESt:SAVEWFM
(Requires TDS3TMT)
Sets or returns the save waveform to file on failure setting. When enabled, this
command copies waveform data from all active channels to files when the
pass/fail test status changes to ‘Failing.’ Set the file save format to Internal File
Format to minimize file size.
NOTE. The oscilloscope saves files only on the first violation that causes the
pass/fail test to fail. To generate a waveform file for every violation occurrence,
set MASK:TESt:REPeat to ON and set MASK:TESt:WAVEform to 1. Use this
technique only when the expected number of violations is small and the violation
occurs intermittently.
Mask
MASK:TESt:SAVEWFM { OFF | ON | <NR1> }
MASK:TESt:SAVEWFM?
OFF turns off copying all active channel waveforms to fils.
ON turns on copying all active channel waveforms to files.
<NR1> is an integer number where NR1 = 0 turns off copying all active channel
waveforms to files, and NR1 ≠ 0 turns on copying all active channel waveforms
to files.
MASK:TEST:SAVEWFM ON
sets the oscilloscope to save the failing waveform data to files.
Examples
Group
Syntax
Arguments
Examples
