Command Descriptions
2- 212
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
NOVershoot is the negative overshoot, expressed as:
NOVershoot = 100 ×
(Low Minimum)
Amplitude
NWIdth is the distance (time) between MidRef (usually 50%) amplitude points of
a negative pulse.
PDUty is the ratio of the positive pulse width to the signal period expressed as a
percentage.
PERIod is the time, in seconds, it takes for one complete signal cycle to happen.
PHAse is the phase dif ference from the selected waveform to the designated
waveform.
PK2pk is the absolute difference between the maximum and minimum amplitude.
It can be used with both general purpose and histogram measurements.
POVershoot is the positive overshoot, expressed as:
POVershoot = 100 ×
(Maximum High)
Amplitude
PWIdth is the distance (time) between MidRef (usually 50%) amplitude points of
a positive pulse.
RISe is the time that it takes for the leading edge of a pulse to rise from a low
reference value to a high reference value of its final value.
RMS is the true Root Mean Square voltage.
MEASUREMENT:IMMED:TYPE FREQUENCY
defines the immediate measurement to be a frequency measurement.
Examples
