Command Groups
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
2-35
Table 2- 25: Trigger comm ands (cont.)
Header Description
TRIGger:A:LOGIc:INPUT<x>:
SOUrce
Sets or returns the signal source for the
specified logic trigger input
TRIGger:A:LOGIc:INPUT<x>:
THReshold
Sets or returns the logic trigger threshold
setting of the specified input
TRIGger:A:LOGIc:PATtern:
DELTATime
Sets or returns the pattern trigger time period
value
TRIGger:A:LOGIc:PATtern:
FUNCtion
Sets or returns the logic function to apply to
the pattern trigger inputs
TRIGger:A:LOGIc:PATtern:
WHEn
Sets or returns the pattern logic condit ion on
which to trigger the oscilloscope
TRIGger:A:LOGIc:STATE:WHEn Sets or returns the state condition on which to
trigger the oscilloscope
TRIGger:A:MODe Trigger mode
TRIGger:A:PULse? Returns the pulse trigger (width, runt, and slew
rate) settings
TRIGger:A:PULse:CLAss Sets or returns the pulse trigger class value
(width, runt, or slew rate)
TRIGger:A:PULse:RUNT? Returns the runt pulse trigger parameters
TRIGger:A:PULse:RUNT:
POLarity
Sets or returns the runt pulse polarity value on
which to trigger the oscilloscope
TRIGger:A:PULse:RUNT:THReshold?
(TDS3TRG)
Returns the runt pulse trigger upper and lower
threshold voltage values
TRIGger:A:PULse:RUNT:
THReshold:BOTh
Sets both runt pulse trigger threshold voltage
values
TRIGger:A:PULse:RUNT:
THReshold:HIGH
Sets or returns the runt pulse trigger high
threshold voltage value
TRIGger:A:PULse:RUNT:
THReshold:LOW
Sets or returns the runt pulse trigger low
threshold voltage value
TRIGger:A:PULse:RUNT:WHEn Sets or returns the runt pulse width condition
on which to trigger the oscilloscope
TRIGger:A:PULse:RUNT: WIDth Sets or returns the runt pulse width time period
value
TRIGger:A:PULse:SLEWRate? Returns the slew rate trigger settings
TRIGger:A:PULse:SLEWRate:
DELTATime
Sets or returns the time component of the slew
rate value
TRIGger:A:PULse:SLEWRate:
POLarity
Sets or returns the slew rate slope polarity on
which to trigger the oscilloscope
TRIGger:A:PULse:SLEWRate:
SLEWrate
Sets or returns the slew rate on which to
trigger the oscilloscope
