Command Groups
2-36
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
Table 2- 25: Trigger commands (cont.)
Header Description
TRIGger:A:PULse:SLEWRate:
THReshold:BOTH
Sets both slew rate threshold voltage values
TRIGger:A:PULse:SLEWRate:
THReshold:HIGH
Sets or returns the slew rate high threshold
voltage value
TRIGger:A:PULse:SLEWRate:
THReshold:LOW
Sets or returns the slew rate low threshold
voltage value
TRIGger:A:PULse:SLEWRate:
WHEn
Sets or returns the slew rate condition on
which to trigger the oscilloscope
TRIGger:A:PULse:SOUrce Sets or returns the signal source for width,
runt, and slew rate triggers
TRIGger:A:PULse:WIDth:POLarity Sets or returns the pulse width polarity value
on which to trigger the oscilloscope
TRIGger:A:PULse:WIDth:WHEn Sets or returns the pulse width condition on
which to trigger the oscilloscope
TRIGger:A:PULse:WIDth:WIDth Sets or returns the pulse width trigger time
period value
TRIGger:A:SETLevel Sets the trigger level to 50%
TRIGger:A:TYPe Sets A trigger to edge, logic, pulse, or, video
type
TRIGger:A:VIDeo? Returns video trigger parameters
TRIGger:A:VIDeo:CUSTom:FORMat
(TDS3SDI, TDS3VID)
Sets or queries the custom video signal source
format
TRIGger:A:VIDeo:CUSTom:SCAN
(TDS3SDI, TDS3VID)
Sets or queries the custom video signal source
scan rate on which to trigger
TRIGger:A:VIDeo:FIELD Sets or queries the field the video trigger
detects
TRIGger:A:VIDeo:HDTV:FORMat
(TDS3SDI, TDS3VID)
Sets or queries the HDTV signal format on
which to trigger
TRIGger:A:VIDeo:HOLdoff:FIELD
(TDS3SDI, TDS3VID)
Sets or queries the number of video fields to
hold off before triggering
TRIGger:A:VIDeo:LINE Sets or queries the video line number on
which to trigger
TRIGger:A:VIDeo:SCAN
(TDS3SDI, TDS3VID)
Sets or queries the video signal source scan
rate on which to trigger
TRIGger:A:VIDeo:SOUrce Selects video trigger source
TRIGger:A:VIDeo:STANdard Selects video trigger standard
TRIGger:A:VIDeo:SYStem Same as TRIGger:A:VIDeo:SOUrce
TRIGger:B? Returns the B tri gger level
