Tektronix TDS6000 Series User Manual

Creating and Using Math Waveforms
3- 224
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
1
0
Amplitude
Time
--92 dB side lobe
0
-- 8 0
dB
Frequency bins
-- 4 0
Figure 3- 58: Time and frequency graphs of the Blackman-Harris window
H Flattop2 Window. This window has the lowest scallop loss of any of the
windows (see Figure 3--59). It also has a wider resolution bandwidth but
lower side lobe attenuation. Also, it is unique because the time domain shape
has negative values.
