Appendix C: Menu Bar Commands
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
C-15
Table C- 10: Math menu commands (Cont.)
Menu FunctionSubmenu
Phase Spectrum Creates a predefined phase spect ral math waveform
Spectral Controls Displays the Spectral Math controls window that you can use to control your
spectral math waveform
Set Math Averages Displays the Math Averaging controls window that you use to set up averaging
in math waveforms
Equation Editor Displays the Math Equation Editor setup window that you use to create math
waveforms
Utilities Commands
Table C--11 lists the commands available from the Utilities menu.
Table C- 1 1: Utilities menu commands
Menu Submenu Function
Tek Secure Erase Erases all setup and ref erence memory
Set Time & Date Displays a menu that you use to set the instrument date and time
GPIB Configuration Displays a control window that you use to set the GPIB talk/listen mode and the
bus address
LAN Server Status Displays the server status window that allows you to turn the server on and off
External Signals Choose the source and polarity of the AUX OUT signal
C
h
t
h
i
t
l
t
l
l
k
f
W
h
h
t
h
Choose the intern
a
lor
a
ne
x
tern
a
l
c
lo
c
kre
f
eren
c
e.
W
hene
v
er
y
ou
c
h
a
nge the
reference, you must perform a signal path compensation, see page 3--172.
Instrument Calibration Displays a window that you use to perform signal path compensation and, if in
service mode, instrument calibration
Instrument Diagnostics Displays a window that you use to run instrument diagnost ics and view the
diagnostic status and error log. If errors are di splayed, refer the instrument to
qualified service personnel
